Newrock HX440G 4 Prot FXO VoIP Gateway
-
- Brand Store: NEWROCK
- Model: Newrock HX440G
- Availability: Out Of Stock
- Part No: HX440G
About this item
Developed for low-port-count applications, such as fax-terminal connectivity, small businesses, SOHO, and residential IP-telephony applications, the MX8G analog VoIP gateway is integrated VoIP-FoIP devices that provide reliable and cost-efficient access methods for deploying converged communication solutions for network operators and enterprises.
The MX8G analog VoIP gateway is designed as a compact unit with 8 FXS/FXO ports, 1 WAN port, and 1 PC port (both are 10/100/1000Mbps Ethernet ports), which allows users to apply it as an all-in-one system capable of providing versatile solutions by connecting analog phone, fax and POS machine, IP telephony, and PSTN.
NEWROCK Newrock HX440G
HARDWARE
FXO Ports : 4
CPU : Dual core, 880MHz
RAM : 256MB
Flash : 16MB
Power Consumption : 6W
Power : 12VDC/1.5A
Mounting : Desktop
PROTOCOLS
Call Control : SIP/UDP and SIP/TCP(RFC3261),IMS(3GPP), MGCP(RFC3435)
Network : SSH, HTTP, HTTPS, DHCP/PPPoE client, Radius, DNS( A/SRV record), STUN
MEDIA PROCESSING
Caller ID : Bellcore/Telcordia, ETSI, BT, DTMF, G.711(a/u), G.729a, G.722, G.722.2* Roadmap feature
DTMF : in – band audio, RFC2833, SIP – INFO
Hook – flash : Local Processing, RFC2833, SIP – INFO
Fax over IP :
T.38, G.711 pass through
T.38 compliant Group 3 Fax
Relay
Maximum frame rate of 33,600bps(T.38)
Disconnect modes : Polarity reversals, Busy tone Detection, Loop current
QoS : DiffServ, TOS, 802.1P/Q VLAN tagging
Voice – quality Enhancement : Echo cancellation (G.168 – 2004), Jitter Buffer, Silence suppression(VAD, CNG), PLC
VOICE
Call transfer : Blind transfer, Consultative transfer
Call forward : call forward all, call forward no answer, call forward busy
Call recording storage : remote recording server for storage
Call settings : routing based on the caller or the callee number , Digit map, 3-way calling, Speed dialling, Do not disturb, call forking, color ring back tones, Hunt group, Ring cadence, Message Waiting Indicator(MWI)
SECURITY
Protocol : HTTPS, TLS, SSH, SRTP
Encryption : Encrypted password/PIN
Intrusion Prevention : Brute force login protection, Access list, Firewall, SIP – allowed IP addresses, Alarm and notification
VLAN : Auto discovery via DHCP, manual configuration
VPN client : L2TP, OpenVPN
HIGH AVAILABILITY
Redundancy : primary – standby, Active – Standby, Load Balancing
PSTN failover : Power failure, Network failure
PROVISIONING, ADMINISTRATION & MAINTENANCE
Device Management : New Rock Unified Management System, (TR – 069, TR – 104 and TR – 106), SNMP
Remote Access over TCP : New Rock Cloud
Auto Provisioning : Download configuration file via TFTP/FTP/HTTP/HTTPS, Obtaining ACS address via DHCP option 66 or redirection
Log management : 8 – level logs, Syslog
Data Capture : Port capture , Packet capture
Status and Statistic : Call status and history, Device status monitoring and statistics collection
Upgrade : Firmware upgrade via Web GUI or Auto provisioning
ADD – ON SOFTWARE
Finder : obtains IP addresses of devices in LAN environment
Telegreeting : Formats pre – prepared IVR audio files or uploads them into a device
Recording agent : receives recording streams in PCM and converts them into MP3 format. Includes management functions such as search, play, delete and backup.
DIMENSIONS & WEIGHT
H*W*D : 30 * 150 * 109(mm)
Net Weight : 0.3kg
| General | |
| Manufacturer | NEWROCK |
|---|---|
| Model | Newrock HX440G |
| Manufacturer Part No | HX440G |
