Yealink MeetingBoard Pro 86" All-in-one MeetingBoard Pro Microsoft Teams Rooms - MB86PRO-A02
-
- Brand Store: Yealink
- Model: Yealink MeetingBoard Pro 86
- Availability: In Stock
- Part No: MB86PRO-A02
Key features
- All-In-One Design
- Built-in Triple-eye Camera with 50MP
- Powerful Camera AI Tracking
- Powerful AI Enhanced Audio
- Intelligent Whiteboard
Yealink Yealink MeetingBoard Pro 86
| Category | Specifications |
|---|---|
| System Overview | • OS: Android 13.0 • Memory: 8GB • Flash: 64GB • CPU: 4x 2.2GHz + 4x 2.0GHz • AI Computing Power: 13.2T FLOPS |
| Display | • Sizes: 65", 75", 86" • Resolution: 3840 x 2160 (4K UHD) • Anti-glare panel • Color Gamut: 72% NTSC / 99% sRGB • Color Depth: 1.07G (10bit) • Contrast: 1200:1 • Brightness: 400 cd/㎡ • Refresh Rate: 60Hz • Viewing Angle: 178° • Motion sensor for system wake-up |
| Touch | • Infrared touch, 20 points • Accuracy: ±1 mm • Height: 1.5 mm • Latency: 21 ms • Four-level stylus support |
| Camera | • Built-in triple 50MP Sony sensors • HFOV: 98.2° • PTZ: Electronic • Zoom: 4x Digital • Autofocus, HDR, WDR • Privacy shutter (electric) • 9 presets • Video: 3840 x 2160 @ 60Hz • Optional Optical Zoom Module (MB-12X Pro): - 8MP, 12x optical zoom - Rotation: ±100° (H), 0°/-90° (V) - DFOV 90°, HFOV 80°, VFOV 49° |
| AI Camera Features | • Auto framing • Speaker tracking • Picture-in-picture (PIP) • IntelliFocus • Video fence |
| Speakers | • Stereo Speakers • Frequency: 90~20KHz • Sensitivity: 87±3 dB SPL @ 0.5m, 1W • THD: <5% at 1KHz, 20W • Rated power: 30W, Max: 36W • Impedance: Tweeter 4Ω, Full-range 8Ω |
| Microphones | • 16 MEMS mic array • Pickup: 12 meters, full-duplex • SNR: 70dB • SPL: 130dB Max, 24dB noise level • Frequency: 20Hz~20KHz • Sensitivity: -38±1dBV/Pa • RCA input supported |
| Video & Sharing | • Lens: up to 4K30fps • HDMI In (local 4K60fps) • In meetings: up to 4K15fps • Wireless: AirPlay, Miracast, Wireless Pod (not in US) |
| Audio Technologies | • Yealink AI Audio 2.1 • Echo, noise, and reverb cancellation • Lip sync, AGC, far-field pickup • Beamforming, CNG/PLC/AJB/De-Reverb |
| Video Codec | H.264 SVC, H.264 High Profile, H.264 |
| Network & Protocols | • Wi-Fi 6 (2x2 MIMO) • Bluetooth 5.1 • TCP/IP (IPv4/IPv6) • DHCP/Static IP • HTTPS |
| Security | • AES-256, SRTP, TLS, H.235 • VLAN, 802.1X, LLDP-MED • HTTPS, OpenVPN • Whitelist/Blacklist, password protection |
| Management | • Config via Web, Touch UI • Debug: RJ45/USB 2.0 • Upgrade: Web, TAC, ZDM, USB • Tools: YMCS, Teams Admin Center, PMP, ZDM • SNMP supported |
| Interfaces | • HDMI Out/In • 3 x USB-A 2.0 • 2 x Gigabit Ethernet • RCA In/Out • RJ45 VCH x2 • OPS Slot, AC power • USB-B Touch, Camera module interface |
| Power Supply | • Input: 100-240V~ 50/60Hz • USB Output: 5V~0.5A • 65": Max 243W, Typical 141W • 75": Max 277W, Typical 164W • 86": Max 357W, Typical 199W |
| Environmental | • Operating Temp: 0–40°C • Storage Temp: -20–60°C • Humidity: 5–95% |
| Packaging Contents | • 1 x MeetingBoard Pro • 3m AC cable, 3m Cat5e cable • 4 x Stylus pens • 3 x Cable ties • Quick Start Guide • MB-WallMount sold separately |
| Device Dimensions & Weight | 65 Pro: - Device: 1484×105×955 mm - Package: 1660×220×1045 mm - With Stand: 1484×778×1887 mm - Net: 40kg, Gross: 50kg |
| Optional Accessories | • Wall/Floor Stands (size-specific) • Microphones: VCM35, VCM36-W, CM20 • Speakers: CS10 • Sharing: VCH51, Wireless Pod • Camera: MB-12X Pro, UVC86 • Controllers: CTP25, MB-Remote • OPS: MCore-OPS, MCore-OPS-T |
| General | |
| Manufacturer | Yealink |
|---|---|
| Model | Yealink MeetingBoard Pro 86 |
| Manufacturer Part No | MB86PRO-A02 |
| UPC | 15604 |
| Compatible Country | Middle East, Africa, Iran, Dubai |
| Country of Origin | China |
| Price | AED 20,475 |
